HLIR is an extremely simple yet powerful syntax for representing low-level instructions in a homoiconic form. It represents a novel synthesis in compiler design by bridging the gap between human and machine representations of programs. By combining monadic composition with homoiconic structure, HLIR allows developers to express computational intent with minimal syntax while maintaining direct mappings to MLIR’s powerful optimization framework.
This marriage of high-level semantics with low-level compilation produces a uniquely ergonomic intermediate representation – one where code is data, transformations are first-class citizens, and optimization becomes natural rather than imposed. The result is a language that is both easy for humans to reason about and efficient for compilers to transform, potentially setting a new standard for intermediate representations in modern compiler design.
In HLIR’s case, this shows up clearly in several design choices:
- Parallel execution as a type hint: You express that parallelism is allowed, not how to parallelize
- Map/reduce as core operations: You express the data transformation pattern, not the loop mechanics
- Type inference: You express what values mean, not how they’re represented
- Block-based structure: You express logical grouping, not control flow details
Key to this design in the PEACE Monad, which stands for Property, Enumerable, Action, Context, and Effect. Not only is it used for blocks (code), expressions (grouping), and lists (data), but it parses and evaluates the HLIR syntax itself. This allows for a simple and powerful representation of code that can be easily transformed into MLIR constructs.
As an added bonus, homoiconicity means HLIR can be configured as an interpreter (executing the intent directly, if inefficiently) or a compiler (generating standard MLIR), or in-between (unfolding concise HLIR into verbose HLIR showing all the inffered types and transformations). This makes it a powerful tool for teaching, debugging, and experimenting with MLIR transformations.
| Concept | HLIR Syntax | MLIR Mapping |
|---|---|---|
| Blocks | { ... }, { { } } |
Regions, Modules |
| Group | expr, statement; (group) |
Elements, Precedenc |
| Types | .name <type> |
Types, Attribute |
| Set Variable | .var <type> 1 |
Block Arguments |
| Expressions | .var expr (expr expr) |
SSA Values |
| List | .list [v1, v2] |
List (auto-typed) |
| Vectors | .v <type> [v1, v2] |
Vector, Tensor, etc. |
| Function Def | .f (.arg <t>)^{ op arg } |
func.func |
| Function Use | f (args) |
func(val) |
| Operations | .val op (arg1, arg2, ...) |
Operations () |
| If-Else | cond ? { then } : { else } |
scf.if |
| Reduce | list | { block } |
scf.reduce |
| Map | list & { block } |
scf.for |
| Parallel Map | v & { block } |
scf.parallel |
| Imports | . <- "foo.hlir" |
Module, Dialects |
| Aliases | .custom <- "foo.hlir" |
Alias Module |
| Arithmetic | +, -, *, /, etc. |
Arithmetic Binary Op |
| Comparison | ==, >>, <<, etc. |
Comparison Binary Op |
| Logical | and, or, not, etc. |
Logical Ops |
| Memory | load, store, etc. |
Memory Management |
| Exceptions | $literal |
Flow Control |
| Visibility | ._protected, .__private |
Scope |
| Effect | var,CONST, mutating: |
Constancy, Mutation |
The key aspects of the HLIR design are:
- Everything is a PEACE monad: blocks, expressions, lists, etc.
- Folding is the same as evaluation (trivial homoiconicity)
- No keywords, only symbols and punctuation
- No loops, only map and reduce operations
- Parallel execution is an (arbitrarily complex) type hint
- Functions use
^to bind arguments (which are also expressions) to blocks - Types are always applied to
.namesnotvalues, and can act as compiler hints - All non-alphanumeric symbols are binary operators (math, comparison)
- Vectors and tensors are represented as typed lists
- Imports merge the module contents into the current context (or an alias)
The compiler would translate this HLIR syntax directly to the corresponding MLIR constructs, handling type inference and other necessary transformations where possible (and providing errors where not). The goal is to make it easy for humans to write and read HLIR code, while still being able to generate efficient MLIR code from it.
HLIR is built using Homoiconic C, which uses monadic parsing and effect typing to provide a simple and powerful data format for deterministic computing.
