TSM-12: RELIGN: A Homoiconic Language for Synchronous, Stateful Reactive Hardware Design

Opening: Setting the Stage

Phil
Good morning, everyone. It’s great to be here at DAC—a conference that brings together the best minds in design automation. For those of you who may not know me, my name is Phil Moorby, and I’m best known as the creator of Verilog, a language that has served the hardware industry for decades.

When I first introduced Verilog, the goal was simple: to make hardware design accessible, efficient, and scalable. But as the years have gone by, our challenges have evolved. The systems we design today are not only larger and more complex but must also integrate seamlessly with software and respect physical constraints like energy and time. Verilog, as powerful as it is, wasn’t built to handle these new demands.

Today, I’m excited to share with you RELIGN, a new programming language that builds on decades of experience while introducing innovative concepts designed for the future of hardware and software co-design.

---

The Problem Today

Phil
Let me start by framing the problem. Traditional hardware description languages like Verilog are static by nature. They were designed to describe hardware structures but lack the flexibility to model modern, adaptive systems. At the same time, event-driven or functional programming models in software are great for reactivity but fall short when it comes to deterministic execution—something hardware requires.

Here’s the kicker: neither of these paradigms adequately handles time or energy as first-class concepts, and yet these are critical for sustainable, efficient design in today’s world.

Phil pauses, letting the gravity of the problem sink in.

This is where RELIGN comes in. RELIGN isn’t just another language—it’s a framework for synchronous, stateful reactive programming (SSRP). It’s built to bridge the gap between hardware and software, offering the deterministic precision of hardware languages and the dynamism of modern programming models.

---

Introducing RELIGN

Phil
So, what makes RELIGN different? Three key principles.

1. Homoiconicity: The language’s structure is its data. This means that RELIGN programs can be interpreted for rapid iteration, compiled for efficiency, or even synthesized into hardware descriptions like Verilog—all without breaking abstraction.

2. First-Class Signals: Signals carry not just values but also timestamps and metadata like energy costs or delays, allowing us to model causality and physical constraints with precision.

3. Hexons: Modular building blocks that encapsulate both behavior—what we call “effect”—and physical constraints, or “affect,” such as time and energy.

---

RELIGN in Action: Modeling, Simulation, and Synthesis

Phil
Let’s see RELIGN in action with a simple example. Here, we’re defining a hexon—a basic building block that takes two inputs, adds them together, and produces one output.

.Adder ^ (.a <i32>, .b <i32>, .sum! <i32>) {
     @sum! a + b
}

This defines the effect: the relationship between inputs and outputs. But RELIGN also tracks the affect—how long the operation takes and how much energy it consumes. By default, every hexon has a time cost of one clock cycle and a small energy cost, though these can be customized.

Phil gestures to a second slide.

Now, let’s simulate this. We define three signals: a, b, and sum. We connect the inputs to the hexon, run a clock cycle, and observe the output.

.in1 <signal> 3;
.in2 <signal> 4;
.out! <signal>;

.adder Adder(in1, in2, out!);
adder.tick();
out  # automatically outputs 7

Here, the interpreter runs RELIGN dynamically, propagating values through the hexon and updating the output signal. The result is 7, as you’d expect. But what’s unique here is that RELIGN also tracks the time spent and energy consumed, which we can analyze later.

Phil (pauses, smiling)
Now, what if we want to deploy this in hardware? RELIGN’s homoiconicity makes this seamless. Let me show you the Verilog code that RELIGN generates for the same example.

    module Adder(
      input [31:0] a,
      input [31:0] b,
      output [31:0] sum
    );
      assign sum = a + b;
    endmodule

In just a few steps, we’ve gone from modeling to simulation to hardware synthesis. That’s the power of RELIGN.

---

Comparisons and Broader Implications

Phil
Let’s take a step back and compare RELIGN to existing paradigms.

• Verilog: Adds dynamism. You can simulate and modify systems on the fly, something Verilog struggles with.
• SIGNAL: Incorporates physical constraints like energy and time, making it more realistic for modern systems.
• Erlang: Offers a reliable stateful actor model but lacks the precision and determinism needed for hardware.
• Reactive Libraries (e.g., RxJS): RELIGN is deterministic and synchronous, perfect for hardware fidelity.

---

Broader Implications and Call to Action

Phil
RELIGN isn’t just a language—it’s a paradigm shift. It bridges hardware and software, enabling true co-design. It introduces energy-aware programming, aligning with today’s demand for sustainability. And it scales from small, modular hexons to complex, distributed systems.

But this is just the beginning. RELIGN’s full potential lies in collaboration. That’s why I’m here—to invite you to join this journey. Whether you’re a hardware designer, a software engineer, or a researcher, RELIGN offers something new and transformative.

Phil looks out at the audience, a thoughtful pause.

Let’s redefine what’s possible in hardware and software design—together.

The audience erupts into applause as Phil steps back from the podium.
